Target Market 10w 20w 30w Led Solar Energy Street Lights System solar garden lighting

Target Market 10w 20w 30w Led
  • Seller Jiangsu Quicklite Technology Development Co., Ltd.
  • Min. Order 1 Set/Sets
  • FOB Price US $200-1200 /Set

Item Details

Port: shanghai/ningbo/yangzhou/nongbo solar led street light
Supply Ability: 5000 Set/Sets per Month
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram,solar led street light

Product Description

Target Market 10w 20w 30w Led Solar Energy Street Lights System solar garden lighting

Recommended products

Product description
Components Parameters
Solar Module Pmax(W) 30-400W
Vmp (V) 35.0V
Imp (A) 2.86A
Light Fixture Material Aluminum die casting & Toughened glass
Operating Temperature -40°C~75°C
Protection Level IP65
LED Light Source LED Chip BRIDGELUX / Cree (Top brand in U.S.A.)
Color Temperature 3800-6500K(white)
Luminous flux 5300 LM
Operating temperature -40°C~75°C
Current Source DC 12V/24V
Power 15W/18W/21W/24W/30W/36W/42W/48W/54W/60W
Lighting Pole Height 3m/ 4m/ 5m/ 6m/ 7m/ 8m/ 9m/ 10m/ 11m/ 12 m
Material BAOSTEEL GROUP Q235/345/GR60
Surface Treatment Hot-dip galvanizing, Static spray,
Size φ60-φ200,δ3-5m, vary according to models
Flange Plate 300*300*16, vary according to models
Battery Capacity 200AH (100AH*2pcs)
Type Gel/AGM Battery
Dimension 546*1203*30
Weight 28Kg
Controller Rated voltage and current 12V/10A or 24V/10A waterproof
Weight 0.165Kg
Two times rainy day backup Two times of rainy day backup.
&Protective Function Good protection: overcharging, discharging, voltage surge, reverse polarity, etc.
Accessories Cable 2.5 mm2, 15m
Battery Box 200AH ABS battery box or metal box with hot-dip galvanizing spray treatment
Foundation Kit Dismountable foundation kit, saving in shipping

Solar Street Light Details

A GRADE high efficient solar panel

Mono: 18% convert efficiency

Poly: 17% convert efficiency

5 years warranty for solar panels

STRONGER POLE with 20 years life time

Larger diameter: our pole is 10% larger in diameters

Thicker wall: we offer 0.25mm thicker pole than that of the market. For example, we offer 3mm thickness for 6m pole, while other, 2.5-2.75mm

Bigger foundation kits: for example, we offer M18-20*1000mm bolts for 6m light, while others, M16-18*800mm

Thicker zinc galvanization and painting: we offer 100 μm zinc and coating than the standard 80 μm

TWO TIMES rainy day backup waterproof controller

Rainy day backup: 2 times more rainy day backup, savings in battery

Combined LED driver and controller as one, easy to maintain

IP67: ideal for high humidity and dust areas

Energy saving mode: THREE periods of power adjustment available

All metal shell: high strength and fast heat dissipation, giving long life time

UL LISTED GEL battery

Long service life (1600 cycles @ 30% DOD)

Better Weather-ability (-20 ºC ~ 50 ºC)

Fully sealed construction


Packaging&Shipping

Our Services

Why Us

One-stop Service

You can find solutions for almost all outdoor lighting from us, like street lighting, square lighting, landscape lighting, traffic lighting and commercial lighting and so on.

Vertically Integrated Production System

You will enjoy high-quality product with cost-effective price from us because we manufacture most of the main components from LED source, light fixture, solar panel, pole and even painting powder to control the cost and quality.

18 Years Manufacturing Experience

Since 1998, we have started manufacturing street lighting. The 15 years’ experiences have been a persuasive insurance for us to offer reliable products.

Large Factory with Complete Facility

We have 400 staffs with factory area 6000 m2. We also equipped with complete production and testing equipments, such as Steel Pole Rolling Machine, Spray Machine, Pressure Machine, Integrating Sphere, Lighting Simulating Machine and Weather-ability Testing Machines, etc . .

Advanced Technology

Our 60 experienced engineering team work with the PV institute of Shanghai FUDAN University , Shenzhen Foxconn to R&D outdoor lighting products. We have obtained over 20 national patents and built our own brand.

Cost Efficiency

Manufacturing main components to save cost. Quicklite manufactures the solar panel, light fixture and pole to control the cost and quality.

Factory outlet. There’s no middleman between the manufacturer Quicklite and domestic and oversea buyers.

Certifications

Terms and Conditions

1. Price Term: EXW, FOB, CFR or CIF.

  • The price includes pole shaft, base plate, crossarm and anchor bolt.
  • Shipping seaport: Shanghai Seaport.
  • Please provide drawings if you have so that we can calculate the accurate price for you.
  • We also provide design according to your requests, if you don't have drawings.

2. MOQ: 1 set for Customized.

3. Payment Term: Typically 30% by T/T as deposit, balance by T/T or L/C at sight before shipment. Other payment way can be negotiated.

4. Delivery Time: 2 weeks per container after PO/drawing/prepayment confirmed.

5. Package: Normally wraped by bubble wrap or melt cloth at the top and bottom,or according to clients requirement.
