Coil slitting process machine line manufacturers

Coil Slitting Process Machine Line Manufacturers
  • Seller Shanghai Honcang Industrial Limited
  • Min. Order 1 Set/Sets slitting machinery
  • FOB Price US $50000-250000 /Set

Item Details

Port: China Port
Supply Ability: 10 Set/Sets per Month slitting machine price
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram

Product Description

Product Description

Introduction of the Steel coil slitter line.

SinoPower steel slitting line with workstations for uncoiling, slitting cut and rolling. It consists of feeding trolley, assisting support, decoiler, pincher, straigntener, slitting cutter, edging machine, tensional machine, recoiler machine, and downloading equipment, hydraulic system and so on. The whole line is controlled by PLC with computer display. The width from 1600mm to2000mm, thicknesses from 0.2mm to 12.0mm and speeds from 30m to 150m/min. Totally computer-controlled with diagnosis, automatic coil feed and quality control.This line is applicable for processing of copper, aluminum, cold-reduced material, hot rolled material, silicon steel, and stainless steel and so on.

steel slitting machine

Steel Slitter Machine Equipment composition

Hydraulic bracket—Carrying coil car—Hydraulic single arm decoiler—Feeding guide plate fitting—pinching machine,coil head shearing—Front looping table—Side guiding fitting—Disc shear—Curling machine—Back looping table—Tension table—Recoiler—Discharging car—Hydraulic bracket—Hydraulic control—Electric control

Slitter Line Specification
Model
SP0.2-1.8×500
SP0.3-2.0×1250(1600)
SP1.0-6.0×1600
SP3.0-12.0×2000
Coil Material
δs≤230N/mm2,Cold-rolled Coil,Hot-rolled Coil,Stainless Coil,Galvanized Coil
Coil Thickness
0.2~1.8mm
0.3~2.0mm
1.0~6.0mm
3.0~12.0mm
Coil Width
100~500mm
800~1250(1600)mm
800~1600mm
1000~2000mm
Coil Weight
≤5T
≤20T(25T)
≤25T
≤30T
Coil Inner Diameter
φ508mm
φ508mm
φ508mm,φ610mm,φ760mm
φ610mm,φ760mm,φ820mm
Coil Outer Diameter
≤φ1600mm
≤φ2000mm
≤φ2000mm
≤φ2000mm
Strip Width
≥25mm
≥30mm
≥50mm
≥80mm
Number Of Strip
5~15
8~20
5~15
4~15
Slitting Accuracy
±0.1mm
±0.15mm
±0.25mm
±0.3mm

Steel Slitter Line Main Features

a.Cutting accuracy and precision thanks to the machine solidity

b.High precise cut to length control

c.High quality on flatness

d.High efficiency for production

e.Delightful man-machine interface coil slitting line

Our Service

Steel Coild Slitter Line Installation and training.

a.If buyers visit our factory and check the coil slitting Line, we will teach you how to install and use the coil slitting machine, and also train your workers/technician face to face;
b.Without visiting, we will send you user manual and video to teach you to install and operate;
c.If buyer needs our technician to go to your local factory, please arrange board and lodging and other necessary things.

Steel Slitter Line After Services.

a.One year guarantee for coil slitting Line;

b.24 hours technical support by email or calling;
c.If there is any problem found of the machine, we will repair it for free in one year.
d.After machinery received,our group will dispatch 2~3 electrical,mechanical engineer abroad, assist buyer
installation coil slitting Line, and train the worker until they can skilled operation alone.
